Model |
Capacity |
Duty |
Rope Reeving |
Lifting Speed |
Lifting Motor（kw） |
Travelling Speed |
Travelling Motor(kw) |
Rail widthrange W（mm） |
Wire Rope Diameter （mm） |
Wheel Diameter （mm） |
A （mm） |
Hmin （mm） |
Lifting height |
|
|
I Beam |
H Beam |
|||||||||||||
|
SHA7 |
1.6 |
M4 |
2/1 |
9/2.2 |
3/0.8 |
20/5 |
0.37/0.1 |
100-180 |
100-400 |
8 |
100 |
220 |
600 |
12/18/24/30 |
|
3.2 |
M4 |
4/1 |
4.5/1.1 |
3/0.8 |
20/5 |
0.37/0.1 |
100-180 |
100-400 |
8 |
100 |
220 |
550 |
6/9/12/15 |
|
|
SHA7 |
3.2 |
M4 |
2/1 |
8/2 |
4.5/1.1 |
20/5 |
0.37/0.1 |
110-180 |
110-460 |
11 |
125 |
220 |
750 |
9/12/18/24 |
|
6.3 |
M4 |
4/1 |
4/1 |
4.5/1.1 |
20/5 |
0.37/0.1 |
110-180 |
110-460 |
11 |
125 |
220 |
650 |
6/9/12 |
|
|
SHA7 |
5 |
M4 |
2/1 |
8/2 |
7.5/2 |
20/5 |
0.37/0.1 |
120-180 |
120-460 |
15 |
150 |
270 |
950 |
12/18/24 |
|
10 |
M4 |
4/1 |
4/1 |
7.5/2 |
20/5 |
0.75/0.18 |
120-180 |
120-460 |
15 |
150 |
270 |
850 |
6/9/12 |
|
-
